AquaSolar GL-235 is America's best-selling entry level microprocessor based solar pool heating control system designed for easy and dependable operation. mixing valves; Pipe fittings incorporating such valves with all movable sealing faces moving as one unit, Multiple-way valves, e.g. GVA-24, Hayward 3-Way Valve For manual solar control PSV3S2 & PSV3S, CLEARANCE: Heliotrope 3-Way FloVerter Valve for automatic solar control. Valve chamber 50 has an inlet 64 for connection to the filter output line 42 (FIG.
I powered the controller using 240 VAC from my pool pump timer, now when the pump is ON, the solar controller is ON. There was an error retrieving your Wish Lists. 12. If you use a manual valve to divert the water to your Enersol Pool Panels, you will need to close/open it every time temperature changes. The limbs of fork 160 extend upwardly through openings in the guide element 164 and bear against the underside of valve element 148. AquaSolar includes exciting customizable features including setting the high temperature limit, programmable freeze protection and water cooling, and a simple single temperature control dial. AquaSolar Time Clock is our premium solar controller. Fork 160 includes two cross members 166 and 168, the lower one of which has a screw threaded opening receiving a complimentarily externally screw threaded member 170 which is turnably mounted in the bottom wall of valve body 48 and which has a squared portion 172 at its lower end received in a square opening in the knob 162. Your session is about to timeout due to inactivity. The drain-down chamber 56 is disposed at the far end of the valve body as seen in FIG. Another problem with many conventional solar heating systems is that thermal syphoning takes place during periods of insufficient solar energy (e.g. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. mixing valves; Pipe fittings incorporating such valves, Multiple-way valves, e.g. When the system is operating in the bypass mode, the pinch valve is closed so that no water flows through the check valve. synthetic rubber). I've just purchased this pool heater to replace an original Hayward that was installed in 2004. Solar pool heating is a smart investment.
A further circular recess 146 is provided in the wall of insert 140 and accomodates part of an adjustment mechanism for the check valve 82. More seriously, there is the risk that the water in the collectors may freeze at night or during unexpected periods of cold weather, for example in fall or spring, unless special precautions are taken to deliberately drain down the collectors. Unfortunately, I may have to change the pipe going to the roof and feeding the solar pipes as the flow coming back down into the pool is very light. It will be seen that the four chambers are disposed end to end with the flow and return chambers on opposite sides of the valve chamber and with the drain-down chamber at the end adjacent the flow chamber 52. Works perfectly! With an auto control system, partially sunny or rainy days are no longer a problem. In other cases, the tube could be connected to the main suction line into the pump, e.g. Hayward, Create a Pool Owner In addition to functioning as a check valve, valve element 148 can be adjusted in the vertical direction so that the valve will also act as a flow control valve for water entering the return chamber 54 through inlet 76. Method and system for positive evacuation of solar collector, Water/swimming pool pump using solar thermal technology enhancing the overall efficiency, Control valve means particularly adapted for swimming pool heater installations embodying a solar heater, Electro-hydraulic regulating valve system, Water/Swimming Pool Pump Using Solar Thermal Technology Enhancing the Overall Efficiency, Solar hot water processor with integrated storage, Freeze protection apparatus for solar collectors, Thermostatic valves, and solar water heating systems incorporating the same, Freeze protection valve for solar heaters, Drain down freeze prevention control system for a solar collector, Automatic control system for water heaters, Prefabricated for pump station pipeline freeze-proof device of rainwater, A kind of water heater low temperature automatic drainage switch valve, Check valve and spring to prevent forward and reverse thermosiphoning in solar collector systems. This unit connects to your main pool pump and does not require a booster pump. 2 by a valve operating rod 58. Includes controller, valve & 24v actuator. 1. please update your current version of Internet Explorer or try using a different browser. Includes LED indicators that shows status of system operations. After viewing product detail pages, look here to find an easy way to navigate back to pages you are interested in. A secondary valve member is provided in association with the drain-down chamber inlet and is operable simultaneously with the primary valve member to close said inlet when the primary valve member is in its said second position, and to open said inlet when the primary valve member is in its first position. A swimming pool containing water is shown at 30 and water inlet and outlet lines associated with the pool are indicated at 32 and 34 respectively. Once the comfort temperature is set the MS3D-V is left to itself to calculate energy ef, cient solar pool heating diverting the water via the automatic three way valve to the roof. 2; and. Accordingly, rod 58 will be constrained to move axially and effect the required displacement of valve member 94. A control valve for a solar heating system is disclosed. Hayward websites have been developed in compliance with standards for Internet Explorer 10 or later. It is sufficient to note that each collector will have upper and lower headers and a collector panel extending between the headers and having a plurality of fluid flow passageways providing communication between the headers. A valve as claimed in claim 1, further comprising float controlled valve means in said drain-down chamber adapted to normally close said outlet from the chamber but to open the outlet in response to a predetermined level of liquid in said chamber. 2). Reference will now be made to FIG. A valve operating rod is movable axially through all four chambers uder motor control and carries a valve member for directing liquid through the valve. 6 is an exploded perspective view of part of FIG. The valve includes a valve body generally denoted 48 in the form of a plastic moulding. A valve as claimed in claim 9, wherein said adjustable means comprises a fork member supported below said valve element for axial sliding movement towards and away from said seat and adapted to support said valve element from below, an actuating element turnably mounted in a wall of said valve body and operable from externally of the body, and screw threaded means coupling said actuating element with said fork so that axial movement of the fork is produced by turning the actuating element. on an intermittently cloudy day) so that heat from the pool is actually lost to ambient air during these periods. The check valve is designed to allow water to flow into inlet 76 in the direction of the arrow in FIG. The seal is held in place by a screw threaded sleeve 180 screwed into a complimentary opening in the exterior of the housing. A sealing gasket 158 surrounds the opening at its lower side and is positioned for co-operation with the valve element 148. 9.
I wish I would have purchased this a long time ago! In this connection, it will be noted that the casing 62 is open at the bottom so that any liquid which might leak into the casing can drain freely away. Return chamber 54 also has an outlet for returning water received from the collectors to the pool. ;ASSIGNOR:STEWART JOHN M.;REEL/FRAME:003835/0252, Free format text: 3 and takes the form of a simple float 106 connected to one arm of a crank 108, the other arm of which carries a valve member 110 for closing outlet 92. Axial movement of valve operating rod 58 to move the valve member 94 between its first and second positions is effected by the motor 60 mentioned above. 2 and is in fact formed by a separate moulding 48a which is solvent welded to the moulding which defines the other three chambers and which forms part of the valve body. This system provides recirculation freeze protection and installer-programmable features for any-system adaptability. Check valve means is associated with the return chamber inlet and is adapted to prevent reverse flow of liquid in the inlet. You can enjoy significant savings and a better pool and spa experience, while being environmentally responsible. According to another aspect of the invention, there is provided a solar heating system incorporated such a control member. training events, warranty At the same time, the water in the collectors will drain down through flow line 22 and into the flow chamber 52.
This mechanism will now be described in more detail primarily with reference to FIGS. Model: FV-2.0, Heliotrope Flowverter Shaft Rebuild Kit Model CV-0232, Jandy 3-Way Valve For manual solar control Model: JV *Out of Stock*, QUANTITY DISCOUNT: Spring Check Valve - PVC 1/2" FPT, Free Shipping, Case: 20 pieces, Pentair PACFAB 3-Way Diverter Valve 1.5" PVC For Manual Solar Control - Part: 263037, Pentair PACFAB 2-Way Diverter Valve 1.5" PVC For Manual Solar Control - Part: 263038, Pentair 3-Way Diverter Valve 2.0" PVC For Manual Solar Control - Part: 263028, Pentair 2-Way Diverter Valve 2.0" PVC For Manual Solar Control - Part: 263029, Pentair 3-Way Diverter Valve 1.5" CPVC For Manual Solar Control - Part: 263035 *Out of Stock*, Pentair 2-Way Diverter Valve 1.5" CPVC For Manual Solar Control - Part: 263036 *Out of Stock*, Pentair 3-Way Diverter Valve 2.0" CPVC COMPOOL For Manual Solar Control - Part: 263026, Pentair 2-Way Diverter Valve 2.0" CPVC For Manual Solar Control - Part: 263027 *Out of Stock*. The opening itself is shown at 88 in FIG. Features single-setting adjustment for desired pool/spa temperature. At the same time, the valve element is free to move upwardly as a result of its natural bouyancy in the event that water enters chamber 54 below the valve element 148. As will be more specifically explained later, valve 44 is a unitary control valve capable of performing all control functions associated with the operation of the solar collectors 26. mixing valves; Pipe fittings incorporating such valves with all movable sealing faces moving as one unit comprising only sliding valves, i.e. SANITARY FAUCET WITH PRESSURE NEUTRAL CERAMIC ELEMENTS, DRIVEN BY STEP MOTORS IN COMBINATION WITH MECHANICAL FRAMEWORKS AND CONTROLLED BY A LIQUID-TIGHT GLASS TEMPERATURE SENSOR UNIT. We strive to ensure that your Totally Hayward System operates at maximum efficiency all season long. Then when the temperature rises the controller will automatically divert the water to the roof. At Hayward, we're more than just equipment. An object of the present invention is to provide an improved control valve for a solar heating system of the kind which includes at least one solar collector having flow and return lines, a reservoir for liquid to be heated, and a pump for circulating liquid from the reservoir through the collector for heating. Did you know that you are still able to draw heat from your roof with the Enersol Pool Heaters 3 or 4 hours after the sun has left? 5 is a sectional view on line V--V of FIG. A valve as claimed in claim 5, wherein said valve means further comprises a reversible electric motor disposed at an end of said valve body and operable from externally of the valve, and means coupling said motor with said valve operating rod and adapted to cause axial movement of the rod in response to operation of the motor. To calculate the overall star rating and percentage breakdown by star, we dont use a simple average. AquaSolar includes exciting customizable features including setting the high temperature limit, programmable freeze protection and water cooling, and a simple single temperature control dial. In any event, in the illustrated embodiment, the drain-down chamber outlet 92 communicates with the suction side of the pump 36 shown in FIG. The valve member 94 is formed by moulding onto an integral disc on rod 58, a ring 134 of a resilient material (e.g. The co-operating screw threads are relatively coarse Acme threads. It is easy to read, understand and operate. By turning knob 162, member 170 will turn and cause axial movement of fork 160 in the appropriate direction and hence adjustment of the position of valve element 148. by way of a T-fitting. The controller has a piggy back plug. The first payment may be due at the time of purchase Yet, partially sunny or rainy days are a challenge. 2 but it is surrounded by a coupling collar 86, part of which is visible. One of these sealing surfaces is indicated at 136 and is defined around an inner face of the annular internal wall which defines the first outlet 68 of chamber 50. 5. search, pool & drain cover safety This unit connects to your main pool pump and does not require a booster pump.
1) will flow through the first outlet 68 of chamber 50 and into the flow chamber 52. Shaft 116 is aligned with the valve operating rod 58 and the rod extends through the adjacent end wall 118 of the valve body 48. Reviewed in the United States on June 18, 2018. service center location, advanced 1) will allow air to enter the solar collectors at this time so that the water can drain freely. A recess 98 is formed in one face of rod portion 96 and is spaced inwardly from the outer end of that portion by an extent such that the recess is disposed in inlet 90 when the primary valve member 94 is in its first position. When the collectors are not in operation, the water is delivered directly from the filter outlet line 42 to the pool return line and the valve is also designed to automatically drain the collectors at this time so as to avoid the problems discussed above involved with allowing the collectors to remain full of water while water from the pool is bypassing the collectors. I opted to purchase a sensor that threads into the drain hole of the pump instead. Profile, Create a Pool Help other Direct Pool Supplies users shop smarter by writing reviews for products you have purchased. at least one solar collector having flow and return lines and vacuum breaker means for admitting air to said collector during draining of water therefrom; a reservoir containing liquid to be heated; means defining a main liquid circulation circuit and having an outlet through which liquid can be removed from said reservoir and an inlet through which liquid can be returned to the reservoir; a pump in said circuit for conveying liquid from said outlet to said inlet; a control valve coupled in said circuit and including: (a) a valve body which defines: a valve chamber having an inlet communicating with said pump for receiving liquid to be heated, and first and second outlets; flow and return chambers communicating respectively with said first and second valve chamber outlets, said flow chamber having an outlet coupled to said solar collector flow line through which liquid can be delivered to the collector, and said return chamber having an inlet coupled to said solar collector return line, said return chamber additionally having an outlet coupled to said circulation circuit inlet through which liquid received from said collector can be returned to the reservoir; a drain-down chamber having an inlet for receiving liquid drained from said collector and an outlet through which drained liquid can be returned to the reservoir, said inlet communicating with said flow chamber; (b) check valve means associated with said return chamber inlet and adapted to prevent reverse flow of liquid in said inlet; (c) valve means including a primary valve member disposed in said valve chamber and movable between first and second positions in which said member closes said first and second valve chamber outlets respectively; valve actuating means operable from externally of said chambers and adapted to move the valve member between its said positions; and a secondary valve member associated with said drain-down chamber inlet and operable simultaneously with said primary valve member to close said inlet when the primary valve member is in its said second position, and to open said inlet when the primary valve member is in its said first position. Read them several times and understand them before starting if a DIY project, especially if you do not have experience in plumbing, pool/spa or electrical fields. BIO-ENERGY SYSTEMS, INC. A CORPORATION OF NEW YO, Free format text: The weight of the float normally maintains valve member 110 in a position in which it closes outlet 92. 1). 2 but to close the inlet under the effect of water flowing in the opposite direction. Go Green with a little help from the sun. The valve member is shown in its second position in FIG. The drain-down chamber has an inlet for receiving liquid drained from the collector, and an outlet through which drained liquid can be returned to the reservoir. If valve member 94 is displaced to close the first outlet 68 of valve chamber 50 (by axially displacing rod 58) incoming water will be diverted from the valve chamber 50 through its outlet 70 and into the return chamber 54. Enjoy automatic maximization of solar heat collection and reliable, accurate performance. A great way to automate your solar pool heating! Then when the temperature rises the controller will automatically divert the water to the roof. It automatically maximizes solar heat collection by actuating a 24V valve when there is solar heat available. The other end of the tube is connected to the suction side of pump 36. Wiring is fairly easy, however setting the limits on the valve adjustment takes some practice. Its like using an air conditioner or furnace without a thermostat. Member 94 is integrally mounted on the valve operating rod 58 so that longitudinal displacement of this rod will cause the valve member to move between its two positions as will be described. Find more information at Enersol Solar Control System page. In order that the invention may be more clearly understood, reference will now be made to the accompanying drawings which illustrate a preferred embodiment of the invention by way of example, and in which: FIG. 5 and 6. The valve has a valve body which defines four chambers disposed end to end. This valve is generally indicated at 104 in FIG. Motor 60 incorporates a speed reduction gear box 114 disposed externally of the motor support casing 62 and having an output shaft 116 which extends into the casing. Check valve 82 comprises a domed valve element 148 having a depending stem 150 which is a free sliding fit in a fixed collar 152 so that the valve element is vertically movable as indicated by the arrow 154 in FIG.
According to the invention, the valve includes a valve body which defines a valve chamber, flow and return chambers, and a drain-down chamber. It will be seen that insert 140 is of generally cylindrical shape and part of the sealing face 138 is visible inside one end of the cylinder. 8. A valve as claimed in claim 3, wherein said valve actuating means comprises a rod mounted for axial movement along said axis of the valve body, wherein said primary valve member is carried by said rod for axial movement therewith between its said first and second positions, and wherein said secondary valve member is disposed at an end portion of said rod adjacent said drain-down chamber inlet. If that valve should leak, the collectors will be gradually pressurized by water flowing in the reverse direction past the check valve because the pinch valve is closed. All AquaSolar controllers automatically divert the water flowing between your pool's filter and heater and route it through solar thermal collectors. Where the valve is connected to a suction line, there is no need to rely on gravity for drainage. Suction line 46 in fact takes the form of a length of plastic tubing which is solvent welded over sleeve 102 but is not shown in FIG. Reviewed in the United States on June 9, 2016.
FIG. A system as claimed in claim 11, wherein said control valve further comprises float control valve means in said drain-down chamber associated with said chamber outlet and adapted to normally close said outlet but to open the outlet in response to a predetermined level of liquid in said chamber; and wherein the system further comprises a suction line connected to said drain-down chamber outlet and to a suction side of said pump whereby liquid draining into said drain-down chamber can be drawn out of said chamber and into the pump when said float control valve means is open. You plug the controller into the chlorinator, then the pump plugs into the piggy back. info. 5. Part 263045, Goldline / Hayward 3-Way Actuator for automatic solar or pool control. You need to have your pool pump running during the day. Two limit switches 128 and 130 are mounted inside casing 62 for co-operation with a disc 132 integrally formed on rod 58 inside casing 62. Further, when the valve is in use, heat loss through the solar collectors of the system due to thermal syphoning is avoided because the collectors will automatically drain down in the event that the valve is operated to cause the water to bypass the collectors. Since the collectors themselves form no part of the present invention, they will not be described in more detail. In practice, the power supply circuit to motor 60 will be a relatively sophisticated automatic control circuit including temperature sensors for automatically operating valve 44 in accordance with temperature conditions prevalent in the system and with ambient temperatures. With a dual digital display, customizable features and full system diagnostic LEDs, AquaSolar TC provides the same reliable solar pool heating and control capabilities of the AquaSolar, but also includes an integral time clock for 24-hour control of the pool's main pump and filtration system. Further, while the preceeding description is directed primarily to solar heating systems for swimming pools, it is to be understood that the invention is not limited in this regard and that the control valve may be used in any liquid-type solar heating system. Our objective is to make your pool experience worry and hassle-free. A control valve of the form provided by the invention is generally indicated at 44 and is connected in the primary circulation circuit formed by the lines 32 and 34 and the pump filter as shown. For example, as indicated above, the float controlled valve arrangement employed in the drain-down chamber 56 is not essential if gravity can be employed to drain water from chamber 56 and return it to the pool. Line 38 is connected to a filter having an output line 42. The only thing I do not like is the incoming water temperature sensor. However, in the event that water accumulates in chamber 56, the float will be lifted, causing the valve member 110 to move away from opening 92 and allow the suction effect of the pump to remove the water from chamber 56. When the temperature cools towards the end of the day, the controller will automatically turn the valve back so the water will stop running through the solar and will go straight back to the pool the normal way. 2. Everything you need to close your pool for winter, FREE Shipping on orders over $25 shipped by Amazon, Upgrade Pool and Spa Projects with the PE24VA Valve Actuator. Owner name: Hayward GLC-1P-A Solar Pool Heating Control System, Hayward AquaSolar GL-235 Controller (Controller only), Hayward Valve Actuator GVA-24 - 180 Deg Rotation, Roof Sensor, 10K Ohm - Roof temperature sensor for Automatic Pool Controller, Water Sensor, 10K Ohm - Pool Temperature sensor for Automatic Pool Controller, Hayward PSV PVC 3-Way Manual Valve (1.5" and 2" Ports), White PVC Ball Valve with Union - 1.5" Slip to Slip, PVC Check Valve - 1.5" Slip to Slip, Schedule 40, White, Ball Valve with Union - White 2" Slip to Slip, White PVC Check Valve - 2" Slip to Slip, Schedule 40. It also analyzed reviews to verify trustworthiness.
I powered the controller using 240 VAC from my pool pump timer, now when the pump is ON, the solar controller is ON. There was an error retrieving your Wish Lists. 12. If you use a manual valve to divert the water to your Enersol Pool Panels, you will need to close/open it every time temperature changes. The limbs of fork 160 extend upwardly through openings in the guide element 164 and bear against the underside of valve element 148. AquaSolar includes exciting customizable features including setting the high temperature limit, programmable freeze protection and water cooling, and a simple single temperature control dial. AquaSolar Time Clock is our premium solar controller. Fork 160 includes two cross members 166 and 168, the lower one of which has a screw threaded opening receiving a complimentarily externally screw threaded member 170 which is turnably mounted in the bottom wall of valve body 48 and which has a squared portion 172 at its lower end received in a square opening in the knob 162. Your session is about to timeout due to inactivity. The drain-down chamber 56 is disposed at the far end of the valve body as seen in FIG. Another problem with many conventional solar heating systems is that thermal syphoning takes place during periods of insufficient solar energy (e.g. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. mixing valves; Pipe fittings incorporating such valves, Multiple-way valves, e.g. When the system is operating in the bypass mode, the pinch valve is closed so that no water flows through the check valve. synthetic rubber). I've just purchased this pool heater to replace an original Hayward that was installed in 2004. Solar pool heating is a smart investment.
A further circular recess 146 is provided in the wall of insert 140 and accomodates part of an adjustment mechanism for the check valve 82. More seriously, there is the risk that the water in the collectors may freeze at night or during unexpected periods of cold weather, for example in fall or spring, unless special precautions are taken to deliberately drain down the collectors. Unfortunately, I may have to change the pipe going to the roof and feeding the solar pipes as the flow coming back down into the pool is very light. It will be seen that the four chambers are disposed end to end with the flow and return chambers on opposite sides of the valve chamber and with the drain-down chamber at the end adjacent the flow chamber 52. Works perfectly! With an auto control system, partially sunny or rainy days are no longer a problem. In other cases, the tube could be connected to the main suction line into the pump, e.g. Hayward, Create a Pool Owner In addition to functioning as a check valve, valve element 148 can be adjusted in the vertical direction so that the valve will also act as a flow control valve for water entering the return chamber 54 through inlet 76. Method and system for positive evacuation of solar collector, Water/swimming pool pump using solar thermal technology enhancing the overall efficiency, Control valve means particularly adapted for swimming pool heater installations embodying a solar heater, Electro-hydraulic regulating valve system, Water/Swimming Pool Pump Using Solar Thermal Technology Enhancing the Overall Efficiency, Solar hot water processor with integrated storage, Freeze protection apparatus for solar collectors, Thermostatic valves, and solar water heating systems incorporating the same, Freeze protection valve for solar heaters, Drain down freeze prevention control system for a solar collector, Automatic control system for water heaters, Prefabricated for pump station pipeline freeze-proof device of rainwater, A kind of water heater low temperature automatic drainage switch valve, Check valve and spring to prevent forward and reverse thermosiphoning in solar collector systems. This unit connects to your main pool pump and does not require a booster pump. 2 by a valve operating rod 58. Includes controller, valve & 24v actuator. 1. please update your current version of Internet Explorer or try using a different browser. Includes LED indicators that shows status of system operations. After viewing product detail pages, look here to find an easy way to navigate back to pages you are interested in. A secondary valve member is provided in association with the drain-down chamber inlet and is operable simultaneously with the primary valve member to close said inlet when the primary valve member is in its said second position, and to open said inlet when the primary valve member is in its first position. A swimming pool containing water is shown at 30 and water inlet and outlet lines associated with the pool are indicated at 32 and 34 respectively. Once the comfort temperature is set the MS3D-V is left to itself to calculate energy ef, cient solar pool heating diverting the water via the automatic three way valve to the roof. 2; and. Accordingly, rod 58 will be constrained to move axially and effect the required displacement of valve member 94. A control valve for a solar heating system is disclosed. Hayward websites have been developed in compliance with standards for Internet Explorer 10 or later. It is sufficient to note that each collector will have upper and lower headers and a collector panel extending between the headers and having a plurality of fluid flow passageways providing communication between the headers. A valve as claimed in claim 1, further comprising float controlled valve means in said drain-down chamber adapted to normally close said outlet from the chamber but to open the outlet in response to a predetermined level of liquid in said chamber. 2). Reference will now be made to FIG. A valve operating rod is movable axially through all four chambers uder motor control and carries a valve member for directing liquid through the valve. 6 is an exploded perspective view of part of FIG. The valve includes a valve body generally denoted 48 in the form of a plastic moulding. A valve as claimed in claim 9, wherein said adjustable means comprises a fork member supported below said valve element for axial sliding movement towards and away from said seat and adapted to support said valve element from below, an actuating element turnably mounted in a wall of said valve body and operable from externally of the body, and screw threaded means coupling said actuating element with said fork so that axial movement of the fork is produced by turning the actuating element. on an intermittently cloudy day) so that heat from the pool is actually lost to ambient air during these periods. The check valve is designed to allow water to flow into inlet 76 in the direction of the arrow in FIG. The seal is held in place by a screw threaded sleeve 180 screwed into a complimentary opening in the exterior of the housing. A sealing gasket 158 surrounds the opening at its lower side and is positioned for co-operation with the valve element 148. 9. I wish I would have purchased this a long time ago! In this connection, it will be noted that the casing 62 is open at the bottom so that any liquid which might leak into the casing can drain freely away. Return chamber 54 also has an outlet for returning water received from the collectors to the pool. ;ASSIGNOR:STEWART JOHN M.;REEL/FRAME:003835/0252, Free format text: 3 and takes the form of a simple float 106 connected to one arm of a crank 108, the other arm of which carries a valve member 110 for closing outlet 92. Axial movement of valve operating rod 58 to move the valve member 94 between its first and second positions is effected by the motor 60 mentioned above. 2 and is in fact formed by a separate moulding 48a which is solvent welded to the moulding which defines the other three chambers and which forms part of the valve body. This system provides recirculation freeze protection and installer-programmable features for any-system adaptability. Check valve means is associated with the return chamber inlet and is adapted to prevent reverse flow of liquid in the inlet. You can enjoy significant savings and a better pool and spa experience, while being environmentally responsible. According to another aspect of the invention, there is provided a solar heating system incorporated such a control member. training events, warranty At the same time, the water in the collectors will drain down through flow line 22 and into the flow chamber 52.
This mechanism will now be described in more detail primarily with reference to FIGS. Model: FV-2.0, Heliotrope Flowverter Shaft Rebuild Kit Model CV-0232, Jandy 3-Way Valve For manual solar control Model: JV *Out of Stock*, QUANTITY DISCOUNT: Spring Check Valve - PVC 1/2" FPT, Free Shipping, Case: 20 pieces, Pentair PACFAB 3-Way Diverter Valve 1.5" PVC For Manual Solar Control - Part: 263037, Pentair PACFAB 2-Way Diverter Valve 1.5" PVC For Manual Solar Control - Part: 263038, Pentair 3-Way Diverter Valve 2.0" PVC For Manual Solar Control - Part: 263028, Pentair 2-Way Diverter Valve 2.0" PVC For Manual Solar Control - Part: 263029, Pentair 3-Way Diverter Valve 1.5" CPVC For Manual Solar Control - Part: 263035 *Out of Stock*, Pentair 2-Way Diverter Valve 1.5" CPVC For Manual Solar Control - Part: 263036 *Out of Stock*, Pentair 3-Way Diverter Valve 2.0" CPVC COMPOOL For Manual Solar Control - Part: 263026, Pentair 2-Way Diverter Valve 2.0" CPVC For Manual Solar Control - Part: 263027 *Out of Stock*. The opening itself is shown at 88 in FIG. Features single-setting adjustment for desired pool/spa temperature. At the same time, the valve element is free to move upwardly as a result of its natural bouyancy in the event that water enters chamber 54 below the valve element 148. As will be more specifically explained later, valve 44 is a unitary control valve capable of performing all control functions associated with the operation of the solar collectors 26. mixing valves; Pipe fittings incorporating such valves with all movable sealing faces moving as one unit comprising only sliding valves, i.e. SANITARY FAUCET WITH PRESSURE NEUTRAL CERAMIC ELEMENTS, DRIVEN BY STEP MOTORS IN COMBINATION WITH MECHANICAL FRAMEWORKS AND CONTROLLED BY A LIQUID-TIGHT GLASS TEMPERATURE SENSOR UNIT. We strive to ensure that your Totally Hayward System operates at maximum efficiency all season long. Then when the temperature rises the controller will automatically divert the water to the roof. At Hayward, we're more than just equipment. An object of the present invention is to provide an improved control valve for a solar heating system of the kind which includes at least one solar collector having flow and return lines, a reservoir for liquid to be heated, and a pump for circulating liquid from the reservoir through the collector for heating. Did you know that you are still able to draw heat from your roof with the Enersol Pool Heaters 3 or 4 hours after the sun has left? 5 is a sectional view on line V--V of FIG. A valve as claimed in claim 5, wherein said valve means further comprises a reversible electric motor disposed at an end of said valve body and operable from externally of the valve, and means coupling said motor with said valve operating rod and adapted to cause axial movement of the rod in response to operation of the motor. To calculate the overall star rating and percentage breakdown by star, we dont use a simple average. AquaSolar includes exciting customizable features including setting the high temperature limit, programmable freeze protection and water cooling, and a simple single temperature control dial. In any event, in the illustrated embodiment, the drain-down chamber outlet 92 communicates with the suction side of the pump 36 shown in FIG. The valve member 94 is formed by moulding onto an integral disc on rod 58, a ring 134 of a resilient material (e.g. The co-operating screw threads are relatively coarse Acme threads. It is easy to read, understand and operate. By turning knob 162, member 170 will turn and cause axial movement of fork 160 in the appropriate direction and hence adjustment of the position of valve element 148. by way of a T-fitting. The controller has a piggy back plug. The first payment may be due at the time of purchase Yet, partially sunny or rainy days are a challenge. 2 but it is surrounded by a coupling collar 86, part of which is visible. One of these sealing surfaces is indicated at 136 and is defined around an inner face of the annular internal wall which defines the first outlet 68 of chamber 50. 5. search, pool & drain cover safety This unit connects to your main pool pump and does not require a booster pump. 1) will flow through the first outlet 68 of chamber 50 and into the flow chamber 52. Shaft 116 is aligned with the valve operating rod 58 and the rod extends through the adjacent end wall 118 of the valve body 48. Reviewed in the United States on June 18, 2018. service center location, advanced 1) will allow air to enter the solar collectors at this time so that the water can drain freely. A recess 98 is formed in one face of rod portion 96 and is spaced inwardly from the outer end of that portion by an extent such that the recess is disposed in inlet 90 when the primary valve member 94 is in its first position. When the collectors are not in operation, the water is delivered directly from the filter outlet line 42 to the pool return line and the valve is also designed to automatically drain the collectors at this time so as to avoid the problems discussed above involved with allowing the collectors to remain full of water while water from the pool is bypassing the collectors. I opted to purchase a sensor that threads into the drain hole of the pump instead. Profile, Create a Pool Help other Direct Pool Supplies users shop smarter by writing reviews for products you have purchased. at least one solar collector having flow and return lines and vacuum breaker means for admitting air to said collector during draining of water therefrom; a reservoir containing liquid to be heated; means defining a main liquid circulation circuit and having an outlet through which liquid can be removed from said reservoir and an inlet through which liquid can be returned to the reservoir; a pump in said circuit for conveying liquid from said outlet to said inlet; a control valve coupled in said circuit and including: (a) a valve body which defines: a valve chamber having an inlet communicating with said pump for receiving liquid to be heated, and first and second outlets; flow and return chambers communicating respectively with said first and second valve chamber outlets, said flow chamber having an outlet coupled to said solar collector flow line through which liquid can be delivered to the collector, and said return chamber having an inlet coupled to said solar collector return line, said return chamber additionally having an outlet coupled to said circulation circuit inlet through which liquid received from said collector can be returned to the reservoir; a drain-down chamber having an inlet for receiving liquid drained from said collector and an outlet through which drained liquid can be returned to the reservoir, said inlet communicating with said flow chamber; (b) check valve means associated with said return chamber inlet and adapted to prevent reverse flow of liquid in said inlet; (c) valve means including a primary valve member disposed in said valve chamber and movable between first and second positions in which said member closes said first and second valve chamber outlets respectively; valve actuating means operable from externally of said chambers and adapted to move the valve member between its said positions; and a secondary valve member associated with said drain-down chamber inlet and operable simultaneously with said primary valve member to close said inlet when the primary valve member is in its said second position, and to open said inlet when the primary valve member is in its said first position. Read them several times and understand them before starting if a DIY project, especially if you do not have experience in plumbing, pool/spa or electrical fields. BIO-ENERGY SYSTEMS, INC. A CORPORATION OF NEW YO, Free format text: The weight of the float normally maintains valve member 110 in a position in which it closes outlet 92. 1). 2 but to close the inlet under the effect of water flowing in the opposite direction. Go Green with a little help from the sun. The valve member is shown in its second position in FIG. The drain-down chamber has an inlet for receiving liquid drained from the collector, and an outlet through which drained liquid can be returned to the reservoir. If valve member 94 is displaced to close the first outlet 68 of valve chamber 50 (by axially displacing rod 58) incoming water will be diverted from the valve chamber 50 through its outlet 70 and into the return chamber 54. Enjoy automatic maximization of solar heat collection and reliable, accurate performance. A great way to automate your solar pool heating! Then when the temperature rises the controller will automatically divert the water to the roof. It automatically maximizes solar heat collection by actuating a 24V valve when there is solar heat available. The other end of the tube is connected to the suction side of pump 36. Wiring is fairly easy, however setting the limits on the valve adjustment takes some practice. Its like using an air conditioner or furnace without a thermostat. Member 94 is integrally mounted on the valve operating rod 58 so that longitudinal displacement of this rod will cause the valve member to move between its two positions as will be described. Find more information at Enersol Solar Control System page. In order that the invention may be more clearly understood, reference will now be made to the accompanying drawings which illustrate a preferred embodiment of the invention by way of example, and in which: FIG. 5 and 6. The valve has a valve body which defines four chambers disposed end to end. This valve is generally indicated at 104 in FIG. Motor 60 incorporates a speed reduction gear box 114 disposed externally of the motor support casing 62 and having an output shaft 116 which extends into the casing. Check valve 82 comprises a domed valve element 148 having a depending stem 150 which is a free sliding fit in a fixed collar 152 so that the valve element is vertically movable as indicated by the arrow 154 in FIG. According to the invention, the valve includes a valve body which defines a valve chamber, flow and return chambers, and a drain-down chamber. It will be seen that insert 140 is of generally cylindrical shape and part of the sealing face 138 is visible inside one end of the cylinder. 8. A valve as claimed in claim 3, wherein said valve actuating means comprises a rod mounted for axial movement along said axis of the valve body, wherein said primary valve member is carried by said rod for axial movement therewith between its said first and second positions, and wherein said secondary valve member is disposed at an end portion of said rod adjacent said drain-down chamber inlet. If that valve should leak, the collectors will be gradually pressurized by water flowing in the reverse direction past the check valve because the pinch valve is closed. All AquaSolar controllers automatically divert the water flowing between your pool's filter and heater and route it through solar thermal collectors. Where the valve is connected to a suction line, there is no need to rely on gravity for drainage. Suction line 46 in fact takes the form of a length of plastic tubing which is solvent welded over sleeve 102 but is not shown in FIG. Reviewed in the United States on June 9, 2016.
FIG. A system as claimed in claim 11, wherein said control valve further comprises float control valve means in said drain-down chamber associated with said chamber outlet and adapted to normally close said outlet but to open the outlet in response to a predetermined level of liquid in said chamber; and wherein the system further comprises a suction line connected to said drain-down chamber outlet and to a suction side of said pump whereby liquid draining into said drain-down chamber can be drawn out of said chamber and into the pump when said float control valve means is open. You plug the controller into the chlorinator, then the pump plugs into the piggy back. info. 5. Part 263045, Goldline / Hayward 3-Way Actuator for automatic solar or pool control. You need to have your pool pump running during the day. Two limit switches 128 and 130 are mounted inside casing 62 for co-operation with a disc 132 integrally formed on rod 58 inside casing 62. Further, when the valve is in use, heat loss through the solar collectors of the system due to thermal syphoning is avoided because the collectors will automatically drain down in the event that the valve is operated to cause the water to bypass the collectors. Since the collectors themselves form no part of the present invention, they will not be described in more detail. In practice, the power supply circuit to motor 60 will be a relatively sophisticated automatic control circuit including temperature sensors for automatically operating valve 44 in accordance with temperature conditions prevalent in the system and with ambient temperatures. With a dual digital display, customizable features and full system diagnostic LEDs, AquaSolar TC provides the same reliable solar pool heating and control capabilities of the AquaSolar, but also includes an integral time clock for 24-hour control of the pool's main pump and filtration system. Further, while the preceeding description is directed primarily to solar heating systems for swimming pools, it is to be understood that the invention is not limited in this regard and that the control valve may be used in any liquid-type solar heating system. Our objective is to make your pool experience worry and hassle-free. A control valve of the form provided by the invention is generally indicated at 44 and is connected in the primary circulation circuit formed by the lines 32 and 34 and the pump filter as shown. For example, as indicated above, the float controlled valve arrangement employed in the drain-down chamber 56 is not essential if gravity can be employed to drain water from chamber 56 and return it to the pool. Line 38 is connected to a filter having an output line 42. The only thing I do not like is the incoming water temperature sensor. However, in the event that water accumulates in chamber 56, the float will be lifted, causing the valve member 110 to move away from opening 92 and allow the suction effect of the pump to remove the water from chamber 56. When the temperature cools towards the end of the day, the controller will automatically turn the valve back so the water will stop running through the solar and will go straight back to the pool the normal way. 2. Everything you need to close your pool for winter, FREE Shipping on orders over $25 shipped by Amazon, Upgrade Pool and Spa Projects with the PE24VA Valve Actuator. Owner name: Hayward GLC-1P-A Solar Pool Heating Control System, Hayward AquaSolar GL-235 Controller (Controller only), Hayward Valve Actuator GVA-24 - 180 Deg Rotation, Roof Sensor, 10K Ohm - Roof temperature sensor for Automatic Pool Controller, Water Sensor, 10K Ohm - Pool Temperature sensor for Automatic Pool Controller, Hayward PSV PVC 3-Way Manual Valve (1.5" and 2" Ports), White PVC Ball Valve with Union - 1.5" Slip to Slip, PVC Check Valve - 1.5" Slip to Slip, Schedule 40, White, Ball Valve with Union - White 2" Slip to Slip, White PVC Check Valve - 2" Slip to Slip, Schedule 40. It also analyzed reviews to verify trustworthiness.
