Sep 11, 2015, THANKS TO ALL FOR ADVICE. doesnt seem like the time dial is advancing ? please help, Posted by doesnt seem like the time dial is advancing ? OK TIMER KICKED ON GUESS JUST NEEDED TO BE PATIENT.. THANKS. Tip: The max point reward for answering a question is 15.
doesnt seem like the time dial is advancing ? - Provide details, support with references or personal experience. Set it for a few hours down the road and you will see that it will turn on and off fine. i can see ONE small gear at very back thru hole is turning nothing else??
All ground wires should be connected to the timer box or themselves. then the clockmotor runs only if timer is switched on. If this is new installation, check wiring. They have little projections on the bottom that turn the timer on/off as the cam moves through its 24 hour rotation.
Incoming power (220v) connects to terminals 1 and 2 (timer power). These are the steps you will need to follow to replace the exsisting T104 (220v) timer with the PE153ME timer. OK TIMER KICKED ON GUESS JUST NEEDED TO BE PATIENT.. THANKS, Complete. THANKS
Set it for a few hours down the road and you will see that it will turn on and off fine. post a close up of the timer and i will tryto assist you.
[oMy214ssz. kZPR v +!!0MJ51F|)&2sK_[nrTB5.Q#D|W;z#fp{dc.RhJw0d. Have a manual for
1) Not likely the timer is problem, unless there was fire or overheating in timer box.
The Intermatic PE153ME is a 3-circuit digital timer and can be used for a variety of purposes. Hot and Load wires might be reversed. You can't post conmments that contain an email address. Are you sure that you put the pins on right? - Better answers use proper spelling and grammar.
Your answer needs to include more details to help people.
Verify that the push-pin jumper is set to 220v on the back of the timer. 1) Copy following links for Intermatic pool timer manuals and wiring: There are many ways to wire T104 timer, depending on what type of load you are controlling and which voltage you have, plus the timer can be converted into different voltages by changing clock motor, or clock motor wiring.
For other applications refer to the installation manual. The little gear in the back is connected to the motor and because it is spinning that tells you that the motor is definitely good. Intermatic 220v T104p Swimming Pool Pump http://waterheatertimer.org/Intermatic-timers-and-manuals.html#pool, http://waterheatertimer.org/Intermatic-trippers-and-parts.html#pool, http://waterheatertimer.org/How-to-wire-T104-Intermatic-timer.html. The email address entered is already associated to an account. It may be time to replace the timer.
Add, See all Intermatic 220v T104p Swimming Pool Pump Timer Questions.
If I understand correctly you have 15 amp breaker with 14gauge wire. its working and advancing appreciate all the help from all
marc kirk Testimonial: "yes i was just wondering bc i put the current time very close to the on pin and it seems like its not moving closer to it to turn it on ? Impossible to set less than an hour into the future .
GOT IT WORKING ;), thanks to all who gave Marc advice on T104 timerits working and advancing appreciate all the help from allhave a great and thanks again to all
Question about Intermatic 220v T104p Swimming Pool Pump Timer Switch, Installed a new timer it turns on and off manually but it seems not automatically. Step 2: Please assign your manual to a product: By entering the Fixya site you declare that you have read and agreed to its Terms. Impossible to set less than an hour into the future .
Tell us some more! THANKS TO ALL FOR ADVICE. Click "Add" to insert your video. You may NOT copy or distribute the content that appears on this site without written permission from Fixya Ltd. 2005-2022, Fixya, Ltd. or it's affiliates.
OK TIMER KICKED ON GUESS JUST NEEDED TO BE PATIENT.. An expert who has finished #1 on the weekly Top 10 Fixya Experts Leaderboard. make sure your line wire is on the correct connection
seems to be connected to the off going contact. Set it for a few hours down the road and you will see that it will turn on and off fine.
Answer questions, earn points and help others, Intermatic 220v T104p Swimming Pool Pump Timer Switch, 220v T104p Swimming Pool Pump Timer Switch, http://waterheatertimer.org/How-to-troubleshoot-Intermatic-timer.html, http://waterheatertimer.org/Intermatic-trippers-and-parts.html#T100, http://waterheatertimer.org/How-to-wire-T104-Intermatic-timer.html#T104, https://www.6ya.com/expert/gene_9f0ef4df2f9897e7, http://waterheatertimer.org/Color-codewire.html#motor.
Use nose and eyes to inspect for signs of high heat.
GOT IT WORKING ;)
Connect jumper wires from terminal 1 to 3 to 5 to 7. Copy following link for step-by-step troubleshoot before ordering replacement WG173 clock motor and 156T1978A trippers. I guess i can wait another hour to see ?". Intermatic 220v T104p Swimming Pool Pump Timer Switch? Impossible to set less than an hour into the future . on 2-speed motor and seal and have run the wiring from the motor to the timer box.
Intermatic WH40 - Water Heater Time Switch - If you need clarification, ask it in the. timer in Mode 4 (pump high, pump low and cleaner pump) only.
GOT IT WORKING ;), thanks to all who gave Marc advice on T104 timer. have a great and thanks again to all, An expert who has achieved level 3 by getting 1000 points.
Study the picture (above) to see proper connections for a 3-circuit connection in Mode 4. I guess i can wait another hour to see ? You can't post answers that contain an email address.
to be sur there is a diagram on electricsuppliesonline.com, search/shop by brand, intermatic. This guide will cover connecting the wiring from the motor to the
This takes in account that you have already replaced the motor and seal with a new Common wire from Polaris motor connects to terminal 8, Hot wire from Polaris motor connects to terminal 2. yes i was just wondering bc i put the current time very close to the on pin and it seems like its not moving closer to it to turn it on ?
good luck, The catch pins might be loose, or the switch may be worn out. thanks to all who gave Marc advice on T104 timer
Common wire to the pump motor connects to terminal 2, High speed wire from pump motor connects to terminal 4, Low speed wire from pump motor connects to terminal 6.
